2 Models and External Dimensions

2 - 12

AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)

The following tables list the Servomotor models by the rated motor speed.

2-3-2 Servomotor Model Tables

3,000-r/min Servomotors

Specifications

Model

Refer-

ence

Without oil seal With oil seal

Straight shaft With key and tap Straight shaft With key and tap

Without brake

100 VAC 50 W R88M-

1M05030S

R88M-

1M05030S-S2

R88M-

1M05030S-O

R88M-

1M05030S-OS2

P. 2 - 4 3

100 W R88M-

1M10030S

R88M-

1M10030S-S2

R88M-

1M10030S-O

R88M-

1M10030S-OS2

P. 2 - 4 5

200 W R88M-

1M20030S

R88M-

1M20030S-S2

R88M-

1M20030S-O

R88M-

1M20030S-OS2

P. 2 - 4 7

400 W R88M-

1M40030S

R88M-

1M40030S-S2

R88M-

1M40030S-O

R88M-

1M40030S-OS2

P. 2 - 4 7

200 VAC 50 W R88M-

1M05030T

R88M-

1M05030T-S2

R88M-

1M05030T-O

R88M-

1M05030T-OS2

P. 2 - 4 3

100 W R88M-

1M10030T

R88M-

1M10030T-S2

R88M-

1M10030T-O

R88M-

1M10030T-OS2

P. 2 - 4 5

200 W R88M-

1M20030T

R88M-

1M20030T-S2

R88M-

1M20030T-O

R88M-

1M20030T-OS2

P. 2 - 4 7

400 W R88M-

1M40030T

R88M-

1M40030T-S2

R88M-

1M40030T-O

R88M-

1M40030T-OS2

P. 2 - 4 7

750 W R88M-

1M75030T

R88M-

1M75030T-S2

R88M-

1M75030T-O

R88M-

1M75030T-OS2

P. 2 - 4 9

1 kW R88M-

1L1K030T

R88M-

1L1K030T-S2

R88M-

1L1K030T-O

R88M-

1L1K030T-OS2

P. 2 - 5 1

1.5 kW R88M-

1L1K530T

R88M-

1L1K530T-S2

R88M-

1L1K530T-O

R88M-

1L1K530T-OS2

P. 2 - 5 1

2 kW R88M-

1L2K030T

R88M-

1L2K030T-S2

R88M-

1L2K030T-O

R88M-

1L2K030T-OS2

P. 2 - 5 1

3 kW R88M-

1L3K030T

R88M-

1L3K030T-S2

R88M-

1L3K030T-O

R88M-

1L3K030T-OS2

P. 2 - 5 3

4 KW R88M-

1L4K030T

R88M-

1L4K030T-S2

R88M-

1L4K030T-O

R88M-

1L4K030T-OS2

P. 2 - 5 5

4.7 KW R88M-

1L4K730T

R88M-

1L4K730T-S2

R88M-

1L4K730T-O

R88M-

1L4K730T-OS2

P. 2 - 5 5

400 VAC 750 W R88M-

1L75030C

R88M-

1L75030C-S2

R88M-

1L75030C-O

R88M-

1L75030C-OS2

P. 2 - 5 7

1 kW R88M-

1L1K030C

R88M-

1L1K030C-S2

R88M-

1L1K030C-O

R88M-

1L1K030C-OS2

P. 2 - 5 7

1.5 kW R88M-

1L1K530C

R88M-

1L1K530C-S2

R88M-

1L1K530C-O

R88M-

1L1K530C-OS2

P. 2 - 5 7

2 kW R88M-

1L2K030C

R88M-

1L2K030C-S2

R88M-

1L2K030C-O

R88M-

1L2K030C-OS2

P. 2 - 5 7

3 kW R88M-

1L3K030C

R88M-

1L3K030C-S2

R88M-

1L3K030C-O

R88M-

1L3K030C-OS2

P. 2 - 5 9

4 KW R88M-

1L4K030C

R88M-

1L4K030C-S2

R88M-

1L4K030C-O

R88M-

1L4K030C-OS2

P. 2 - 6 1

5 KW R88M-

1L5K030C

R88M-

1L5K030C-S2

R88M-

1L5K030C-O

R88M-

1L5K030C-OS2

P. 2 - 6 1

Omron R88D-1SN ECT Series Specifications

General

Feedback	Incremental encoder, Absolute encoder
Position Control	Yes
Speed Control	Yes
Torque Control	Yes
Communication Interface	EtherCAT
Power Supply Voltage	200 to 240 VAC
Output Power	0.1 to 1.5 kW
Input Voltage Range	170 to 264 VAC
Control Method	Sine-wave PWM control
Main Circuit Power Supply	200-240 VAC
Applicable Motor Capacity	0.1 to 1.5 kW
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Encoder Error
Ambient Operating Temperature	0 to 55°C
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
Shock Resistance	98 m/s2
Weight	Varies by model
