9 - 31
9 Details on Servo Parameters
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
9-3 Control Method Objects
9
9-3-4 3121 hex: TDF Velocity Control
Sets the following performance for the target position.
The higher the gain is, the higher the following performance of the internal command is for the target
position.
The set value is valid when TDF Position Control - Command Following Gain Selection (3120-10
hex) is set to 0 (use the Command Following Gain).
Selects the command following gain switching method.
Description of Set Values
Sets the cutoff frequency to the position command.
The higher the set value is, the higher the following performance of the internal command is for the
target position.
The set value is valid when TDF Position Control - Command Following Gain Selection (3120-10
hex) is set to 1 (use the Command Following Gain 2).
Sets the operation in the two-degree-of-freedom velocity control.
Subindex 01 hex: Command Following Gain
Subindex 10 hex: Command Following Gain Selection
Set
value
Description
0 Use the Command Following Gain.
1 Use the Command Following Gain 2.
Subindex 11 hex: Command Following Gain 2
9-3-4 3121 hex: TDF Velocity Control
Index
(hex)
Sub-
index
(hex)
Object name
Setting
range
Unit
Default
setting
Data
attri-
bute
Size Access
PDO
map
Complete
access
Modes of
operation
3121 --- TDF Velocity
Control
--- --- --- --- --- --- --- Possible ---
00 Number of
entries
--- --- 01 hex --- 1 byte
(U8)
RO --- --- ---
01 Command Fol-
lowing Gain
10 to
5,000
% 100 A 4 bytes
(INT32)
RW --- --- csv, pv
10 Command Fol-
lowing Gain
Selection
*1
*1. These objects are available for the unit version 1.1 or later.
0 to 1 --- 0 A 4 bytes
(INT32)
RW --- --- csv, pv
11 Command Fol-
lowing Gain 2
*1
1 to
50,000
0.1 Hz 219/146
*2
*2. The first value is for the Servo Drive with its capacity 3kw or less. The second value is for the Servo Drive with its capacity
5kw or more.
A 4 bytes
(INT32)
RW --- --- csv, pv
