11-8 Load Characteristic Estimation
11
11-8-1 Objects Requiring Settings
11-8-1 Objects Requiring Settings
Index
(hex)
Subindex
(hex)
Name Description
Refer-
ence
3B80
---
Load Characteristic
Estimation
Sets the operation of the load characteristic estimation. P. 9-78
01 Inertia Ratio Update
Selection
Selects whether to estimate load characteristics and update a
value of the inertia ratio.
0: Use the present set value.
1: Update with the estimation result.
P. 9-78
02 Viscous Friction Com-
pensation Update
Selection
Selects whether to estimate load characteristics and update a
value of the viscous friction coefficient.
0: Use the present set value.
1: Update with the estimation result.
P. 9-78
03 Unbalanced Load
Compensation Update
Selection
Selects whether to estimate load characteristics and update a
value of the unbalanced load compensation.
0: Use the present set value.
1: Update with the estimation result.
P. 9-79
04 Dynamic Friction Com-
pensation Update
Selection
Selects whether to estimate load characteristics and update a
value of the dynamic friction compensation.
0: Use the present set value.
1: Update with the estimation result.
P. 9-79
05 Viscous Friction Tun-
ing Coefficient
Sets the value to adjust the amount of torque compensation
which is calculated from the estimated viscous friction value.
When the viscous friction coefficient update is enabled, the
viscous friction coefficient is updated with a value which is
calculated by multiplying the estimated viscous friction by the
amount of viscous friction compensation.
P. 9-79
06 Estimation Sensitivity
Selection
Selects the sensitivity to estimate load characteristics from
load changes during the load characteristic estimation.
0: Estimate by minutes from load characteristic changes.
This setting is used when there is a little change in load char-
acteristics.
1: Estimate by seconds from load characteristic changes.
This setting is used when there is a gradual change in load
characteristics.
2: Estimate immediately from load characteristic changes.
This setting is used when there is a sharp change in load
characteristics.
P. 9-79
FF Estimation Status Gives the execution status of the load characteristic estima-
tion.
0: Never executed
1: Obtaining data
2: During estimation
3: Estimation completed
P. 9-80

Omron R88D-1SN ECT Series Specifications

General

Feedback	Incremental encoder, Absolute encoder
Position Control	Yes
Speed Control	Yes
Torque Control	Yes
Communication Interface	EtherCAT
Power Supply Voltage	200 to 240 VAC
Output Power	0.1 to 1.5 kW
Input Voltage Range	170 to 264 VAC
Control Method	Sine-wave PWM control
Main Circuit Power Supply	200-240 VAC
Applicable Motor Capacity	0.1 to 1.5 kW
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Encoder Error
Ambient Operating Temperature	0 to 55°C
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
Shock Resistance	98 m/s2
Weight	Varies by model
