Omron R88D-1SN ECT Series User Manual

2 - 35
2 Models and External Dimensions
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
2-3 Model Tables
2
2-3-10 Noise Filter Model Table
The following table lists the Footprint-type Noise Filter models.
For a recommended noise filter for applicable Servomotor at 5.5 kW or more, refer to 4-3 Wiring Con-
forming to EMC Directives on page 4-47.
2-3-10 Noise Filter Model Table
Applicable Servo Drive Model
R88D-1SN01L-ECT/-1SN01H-ECT/-1SN02H-ECT (Single-phase input) R88A-FI1S103
R88D-1SN02L-ECT/-1SN04H-ECT (Single-phase input) R88A-FI1S105
R88D-1SN04L-ECT/-1SN08H-ECT (Single-phase input) R88A-FI1S109
R88D-1SN15H-ECT (Single-phase input) R88A-FI1S116
R88D-1SN01H-ECT/-1SN02H-ECT (3-phase input) R88A-FI1S202 or R88A-FI1S203
R88D-1SN04H-ECT (3-phase input) R88A-FI1S203
R88D-1SN08H-ECT (3-phase input) /-1SN10H-ECT R88A-FI1S208
R88D-1SN15H-ECT (3-phase input) /-1SN20H-ECT/-1SN30H-ECT R88A-FI1S216
R88D-1SN06F-ECT/-1SN10F-ECT/-1SN15F-ECT/-1SN20F-ECT/
-1SN30F-ECT
R88A-FI1S309

Omron R88D-1SN ECT Series Specifications

General

Feedback	Incremental encoder, Absolute encoder
Position Control	Yes
Speed Control	Yes
Torque Control	Yes
Communication Interface	EtherCAT
Power Supply Voltage	200 to 240 VAC
Output Power	0.1 to 1.5 kW
Input Voltage Range	170 to 264 VAC
Control Method	Sine-wave PWM control
Main Circuit Power Supply	200-240 VAC
Applicable Motor Capacity	0.1 to 1.5 kW
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Encoder Error
Ambient Operating Temperature	0 to 55°C
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
Shock Resistance	98 m/s2
Weight	Varies by model
