2 Models and External Dimensions
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
2-3 Model Tables
2
2-3-5 Servomotor and Decelerator Combination Tables
The following tables show the possible combinations of 1S-series Servomotors and Decelerators. You
cannot use a Servomotor with a key and tap (model numbers with -S2 at the end) in combination with a
Decelerator.
 Combinations of 3,000-r/min motors and decelerators
 Combinations of 2,000-r/min motors and decelerators
2-3-5 Servomotor and Decelerator Combination Tables
Backlash: 3 Arcminutes Max.
Servomotor
models
Reduction ratio
1/5 1/11 1/21 1/33 1/45
R88M-
1M05030
--- ---
R88G-HPG
14A21100B
R88G-HPG
14A33050B
R88G-HPG
14A45050B
R88M-
1M10030
R88G-HPG
11B05100B
R88G-HPG
14A11100B
R88G-HPG
20A33100B
R88G-HPG
20A45100B
R88M-
1M20030
R88G-HPG
14A05200B
R88G-HPG
14A11200B
R88G-HPG
20A21200B
R88G-HPG
20A33200B
R88G-HPG
20A45200B
R88M-
1M40030
R88G-HPG
14A05400B
R88G-HPG
20A11400B
R88G-HPG
20A21400B
R88G-HPG
32A33400B
R88G-HPG
32A45400B
R88M-
1M75030
(200 VAC)
R88G-HPG
20A05750B
R88G-HPG
20A11750B
R88G-HPG
32A21750B
R88G-HPG
32A33750B
R88G-HPG
32A45750B
R88M-
1L75030
(400 VAC)
R88G-HPG
32A052K0B
R88G-HPG
32A112K0B
R88G-HPG
32A211K5B
R88G-HPG
32A33600SB
R88G-HPG
50A451K5B
R88M-
1L1K030
R88G-HPG
50A332K0B
R88M-
1L1K530
R88M-
1L2K030
R88G-HPG
50A212K0B
---
R88M-
1L3K030
R88G-HPG
32A053K0B
R88G-HPG
50A113K0B
R88G-HPG
50A213K0B
--- ---
R88M-
1L4K030
R88G-HPG
32A054K0B
R88G-HPG
50A115K0B
--- --- ---
R88M-
1L4K730
R88G-HPG
50A055K0B
--- --- ---
R88M-
1L5K030
--- --- ---
Servomotor
models
Reduction ratio
1/5 1/11 1/21 1/25 1/33 1/45
R88M-
1M40020
(400 VAC)
R88G-HPG
32A052K0B
R88G-HPG
32A112K0B
R88G-HPG
32A211K5B
---
R88G-HPG
32A33600SB
R88G-HPG
32A45400SB
R88M-
1M60020
(400 VAC)
---
R88G-HPG
50A451K5B
R88M-
1M1K020
R88G-HPG
32A053K0B
R88G-HPG
32A112K0SB
R88G-HPG
32A211K0SB
---
R88G-HPG
50A332K0SB
R88G-HPG
50A451K0SB
R88M-
1M1K520
R88G-HPG
50A213K0B
--- ---
R88M-
1M2K020
--- ---
R88M-
1M3K020
R88G-HPG
32A054K0B
R88G-HPG
50A115K0B
R88G-HPG
50A213K0SB
R88G-HPG
65A253K0SB
--- ---
