Omron R88D-1SN ECT Series User Manual

1 - 31
1 Features and System Configuration
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
1-5 Applicable Standards
1
1-5-3 Korean Radio Regulations (KC)
• The Servo Drives with its capacity 5.5 kW or more
Use the UL-listed breaker or UL class fuse (RK5, CC, CF, G, J, R or T) which has the rated current
in the table.
• Observe the following precaution if you use this product in Korea.
Guide for Users
This equipment has been evaluated for conformity in a commercial environment.
When used in a residential environment, it may cause radio interference.
• The 1S-series Servo Drives comply with the Korean Radio Regulations (KC).
• The 1S-series Servomotors are exempt from the Korean Radio Regulations (KC).
• The main power supply inputs can conform to the SEMI F47 standard for momentary power interrup-
tions (voltage sag immunity) for no-load operation.
• This standard applies to semiconductor manufacturing equipment.
Precautions for Correct Use
• This standard does not apply to the 24-VDC control power input. Use the power supply.
• This standard does not apply to single-phase 100-V Servo Drives.
• Be sure to perform evaluation tests for SEMI F47 compliance in the entire machine and system.
R88D-1SN01H-ECT UL CLASS RK5 15 A
R88D-1SN02H-ECT UL CLASS RK5 15 A
R88D-1SN04H-ECT UL CLASS RK5 15 A
R88D-1SN08H-ECT UL CLASS RK5 15 A
R88D-1SN10H-ECT UL CLASS RK5 15 A
R88D-1SN15H-ECT UL CLASS RK5 40 A
R88D-1SN20H-ECT UL CLASS RK5 40 A
R88D-1SN30H-ECT UL CLASS RK5 40 A
R88D-1SN06F-ECT UL CLASS RK5 20 A
R88D-1SN10F-ECT UL CLASS RK5 20 A
R88D-1SN15F-ECT UL CLASS RK5 20 A
R88D-1SN20F-ECT UL CLASS RK5 20 A
R88D-1SN30F-ECT UL CLASS RK5 20 A
Servo Drive model Voltage (Minimum) Ampere
R88D-1SN55H-ECT 240 V 60 A
R88D-1SN75H-ECT 240 V 60 A
R88D-1SN150H-ECT 240 V 125 A
R88D-1SN55F-ECT 480 V 30 A
R88D-1SN75F-ECT 480 V 30 A
R88D-1SN150F-ECT 480 V 60 A
1-5-3 Korean Radio Regulations (KC)
1-5-4 SEMI F47
Servo Drive model Fuse

Omron R88D-1SN ECT Series Specifications

General

Feedback	Incremental encoder, Absolute encoder
Position Control	Yes
Speed Control	Yes
Torque Control	Yes
Communication Interface	EtherCAT
Power Supply Voltage	200 to 240 VAC
Output Power	0.1 to 1.5 kW
Input Voltage Range	170 to 264 VAC
Control Method	Sine-wave PWM control
Main Circuit Power Supply	200-240 VAC
Applicable Motor Capacity	0.1 to 1.5 kW
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Encoder Error
Ambient Operating Temperature	0 to 55°C
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
Shock Resistance	98 m/s2
Weight	Varies by model
