Omron R88D-1SN ECT Series User Manual

5 EtherCAT Communications
5 - 24
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
The following table shows the relation between the network configuration information downloaded in an
NJ/NX-series CPU Unit supporting the cable redundancy function and the actual configuration.
5-9-5 Relation between the Network Configuration Information and the
Actual Configuration
No.
Network Con-
figuration
Information
Actual Configura-
tion
EtherCAT
Communica-
tions Status
Communications Status with a Cable Dis-
connected or Broken
1 Daisy chain
and branching
topology only
Daisy chain and
branching topol-
ogy only (same as
the network config-
uration informa-
tion)
Normal status The communications status changes to the
minor fault status in which part of the slaves can
continue communications.
*1
*1. If a minor fault occurs, slaves not separated from the EtherCAT master operate according to Fail-soft Opera-
tion Setting of the CPU Unit. Slaves separated from the EtherCAT master cannot continue communications.
Refer to the NJ/NX-series CPU Unit Built-in EtherCAT Port User’s Manual (Cat. No. W505) for details on
Fail-soft Operation Setting.
2 Contains the ring
topology
Minor fault All slaves can continue communications.
Removing a cable added from the network con-
figuration information and resetting the error
returns the communications status to the status
of No. 1.
3 Contains the
ring topology
Daisy chain and
branching topol-
ogy only
Ring disconnec-
tion status
The communications status changes to the
minor fault status in which part of the slaves can
continue communications.
*1
4 Contains the ring
topology (same as
the network config-
uration informa-
tion)
Normal status The communications status changes to the ring
disconnection status in which all slaves can
continue communications. If a cable is discon-
nected or broken in this status, the status
changes to the minor fault status in which part
of the slaves can continue communications.
*1

Omron R88D-1SN ECT Series Specifications

General

Feedback	Incremental encoder, Absolute encoder
Position Control	Yes
Speed Control	Yes
Torque Control	Yes
Communication Interface	EtherCAT
Power Supply Voltage	200 to 240 VAC
Output Power	0.1 to 1.5 kW
Input Voltage Range	170 to 264 VAC
Control Method	Sine-wave PWM control
Main Circuit Power Supply	200-240 VAC
Applicable Motor Capacity	0.1 to 1.5 kW
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Encoder Error
Ambient Operating Temperature	0 to 55°C
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
Shock Resistance	98 m/s2
Weight	Varies by model
