Omron R88D-1SN ECT Series User Manual

Related Manuals
40
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
Related Manuals
The following are the manuals related to this manual. Use these manuals for reference.
Manual name Cat. No. Model numbers Application Description
NX-series CPU
Unit Hardware
User’s Manual
W535 NX701- Learning the basic speci-
fications of the NX-series
CPU Units, including
introductory information,
designing, installation,
and maintenance.
Mainly hardware infor-
mation is provided.
An introduction to the entire
NX-series system is pro-
vided along with the follow-
ing information on the CPU
Unit.
• Features and system con-
figuration
• Introduction
• Part names and functions
• General specifications
• Installation and wiring
• Maintenance and inspec-
tion
Use this manual together
with the NJ-series CPU Unit
Software User’s Manual
(Cat. No. W501).
NX-series NX102
CPU Unit
Hardware User’s
Manual
W593 NX102- Learning the basic speci-
fications of the NX102
CPU Units, including
introductory information,
designing, installation,
and maintenance.
Mainly hardware infor-
mation is provided.
An introduction to the entire
NX102 system is provided
along with the following infor-
mation on the CPU Unit.
• Features and system con-
figuration
• Introduction
• Part names and functions
• General specifications
• Installation and wiring
• Maintenance and inspec-
tion
NX-series NX1P2
CPU Unit
Hardware User's
Manual
W578 NX1P2- Learning the basic speci-
fications of the NX1P2
CPU Units, including
introductory information,
designing, installation,
and maintenance.
Mainly hardware infor-
mation is provided.
An introduction to the entire
NX1P2 system is provided
along with the following infor-
mation on the CPU Unit.
• Features and system con-
figuration
• Introduction
• Part names and functions
• General specifications
• Installation and wiring
• Maintenance and inspec-
tion

Omron R88D-1SN ECT Series Specifications

General

Feedback	Incremental encoder, Absolute encoder
Position Control	Yes
Speed Control	Yes
Torque Control	Yes
Communication Interface	EtherCAT
Power Supply Voltage	200 to 240 VAC
Output Power	0.1 to 1.5 kW
Input Voltage Range	170 to 264 VAC
Control Method	Sine-wave PWM control
Main Circuit Power Supply	200-240 VAC
Applicable Motor Capacity	0.1 to 1.5 kW
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Encoder Error
Ambient Operating Temperature	0 to 55°C
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
Shock Resistance	98 m/s2
Weight	Varies by model
