2 - 37
2 Models and External Dimensions
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
2-4 External and Mounting Dimensions
2
2-4-1 Servo Drive Dimensions
Single-phase 100 VAC: R88D-1SN02L-ECT (200 W)
Single-phase/3-phase 200 VAC: R88D-1SN04H-ECT (400 W)
External
dimensions
Mounting dimensions
4
4518070
50
185
3.2
55
2-M4
55
43±0.56
170±0.55
180
M4
M4
2-M4
