Omron R88D-1SN ECT Series

2 - 41
2 Models and External Dimensions
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
2-4 External and Mounting Dimensions
2
2-4-1 Servo Drive Dimensions
3-phase 200 VAC: R88D-1SN150H-ECT (15 kW)
160±0.5
466±0.517.5
220
4-M6
30
496
50
2
250
170400450
Air intake
Air outlet
External
dimensions
Mounting dimensions
Shield Clamp
2-M5
220
46
75.2
