7 Applied Functions

AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)

7-14 Communications Error Period Command Correction Function

7-14-2 Operation Example

Without this function, the target positions will not be corrected and become as follows.

Velocity of

Position Command

When a communications

error occurs

When no communications

error occurs

Communications

error occurs

Communications

error occurs
