Omron R88D-1SN ECT Series User Manual

8 - 11
8 Safety Function
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
8-3 STO Function via EtherCAT Communications
8
8-3-1 Connection and Setting
1 Add Safety PDOs to the 1S-series Servo Drive PDOs in the EtherCAT network configuration.
• RxPDO: 273th receive PDO Mapping (1710 hex)
• TxPDO: 273th transmit PDO Mapping (1B10 hex)
2 Enable the 1S-series Servo Drive in the setting for the Safety CPU Unit.
3 Use the following data and create safety programs for the Safety CPU Unit.
4 Establish communications between the EtherCAT master and the Safety CPU Unit.
The STO function is enabled when communications with the Safety CPU Unit are established
once.
If the communications cannot be established after you change the Safety CPU Unit setting,
clear the FSoE slave address.
Precautions for Correct Use
• When you use the STO function via EtherCAT communications, enable the security function
of the EtherCAT master so that the PDO mapping is not changed.
• Use the Operation Authority Verification function in the NJ/NX-series CPU Unit to enable the
security function. Set authorities so that synchronization of the transfer operations cannot be
operated. Refer to the Sysmac Studio Version 1 Operation Manual (Cat. No. W504) for
details.
• When communications with the EtherCAT master are established, the STO status is detected
and the 7-segment LED display shows “ST”. Reset STO after communications with the
Safety CPU Unit are established.
 RxPDO (1710 hex)
 TxPDO (1B10 hex)
Setting
Name Description
STO command Performs the STO function.
0: Activate STO
1: Reset STO
Error acknowledge reset Resets an error of the safety function on the rising edge from 0 to 1.
Name Description
STO status Gives the status of the STO function.
0: Normal status
1: STO status
Error acknowledge Gives the error status of the safety function.
0: No error
1: STO internal circuit error detection
Safety Connection Status This flag indicates that the safety connection is in progress. The flag is used
for inputting to the Activate terminal for the safety program, or it is used in the
safety connection/disconnection application.

Omron R88D-1SN ECT Series Specifications

General

Feedback	Incremental encoder, Absolute encoder
Position Control	Yes
Speed Control	Yes
Torque Control	Yes
Communication Interface	EtherCAT
Power Supply Voltage	200 to 240 VAC
Output Power	0.1 to 1.5 kW
Input Voltage Range	170 to 264 VAC
Control Method	Sine-wave PWM control
Main Circuit Power Supply	200-240 VAC
Applicable Motor Capacity	0.1 to 1.5 kW
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Encoder Error
Ambient Operating Temperature	0 to 55°C
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
Shock Resistance	98 m/s2
Weight	Varies by model
