1 Features and System Configuration
1 - 18
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
Flange Size of 100 × 100 or more
Flange Size of 130 × 130 or more (4 kW or more)
Power/brake connector
Encoder
connector
Flange
Mating part
Shaft
200 VAC 1.5 kW Servomotors (with Brake)
Power/brake connector
Encoder connector
Flange
Mating part
Shaft
200 VAC 4 kW Servomotors (with Brake)
Eye-bolt
