9 Details on Servo Parameters
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
9-14 I/O-related Objects
9
9-14-2 4601 hex: Function Input
20 Monitor Input 1 MON1 0 OFF
1ON
21 Monitor Input 2 MON2 0 OFF
1ON
22 Monitor Input 3 MON3 0 OFF
1ON
23 Positive Torque Limit Input PCL 0 OFF
1ON
24 Negative Torque Limit Input NCL 0 OFF
1ON
25 Error Stop Input ESTP 0 OFF
1ON
26 Brake Interlock Output BKIR 0 Brake held
1 Brake released
27 Safety input 1 SF 0 OFF
1ON
28 Safety input 2 SF 0 OFF
1ON
29 EDM Output EDM 0 OFF
1ON
30 Monitor Input 4 MON4 0 OFF
1ON
31 Monitor Input 5 MON5 0 OFF
1ON
Bit Signal name Symbol Value Description

Omron R88D-1SN ECT Series Specifications

General

Feedback	Incremental encoder, Absolute encoder
Position Control	Yes
Speed Control	Yes
Torque Control	Yes
Communication Interface	EtherCAT
Power Supply Voltage	200 to 240 VAC
Output Power	0.1 to 1.5 kW
Input Voltage Range	170 to 264 VAC
Control Method	Sine-wave PWM control
Main Circuit Power Supply	200-240 VAC
Applicable Motor Capacity	0.1 to 1.5 kW
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Encoder Error
Ambient Operating Temperature	0 to 55°C
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
Shock Resistance	98 m/s2
Weight	Varies by model
