Omron R88D-1SN ECT Series User Manual

9 - 115
9 Details on Servo Parameters
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
9-14 I/O-related Objects
9
9-14-7 4620 hex: Encoder Dividing Pulse Output
• For applications for which the number of output pulses per rotation is not an integer, set this object to
a value other than 0. By setting a value other than 0, the number of output pulses per motor rotation
can be set with the dividing ratio which is calculated from the dividing numerator and dividing denom-
inator.
 Description of Set Values
• Selects whether to reverse the encoder dividing pulse output or not.
 Description of Set Values
Subindex 03 hex: Dividing Denominator
Set value Description
0 Number of output pulses per rotation = Encoder Dividing Numerator × 4
Others Number of output pulses per rotation = Encoder Dividing Numerator ÷ Encoder Dividing
Denominator × Encoder Resolution
Subindex 04 hex: Output Reverse Selection
Set value Description
0 Not reverse
1 Reverse

Omron R88D-1SN ECT Series Specifications

General

Feedback	Incremental encoder, Absolute encoder
Position Control	Yes
Speed Control	Yes
Torque Control	Yes
Communication Interface	EtherCAT
Power Supply Voltage	200 to 240 VAC
Output Power	0.1 to 1.5 kW
Input Voltage Range	170 to 264 VAC
Control Method	Sine-wave PWM control
Main Circuit Power Supply	200-240 VAC
Applicable Motor Capacity	0.1 to 1.5 kW
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Encoder Error
Ambient Operating Temperature	0 to 55°C
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
Shock Resistance	98 m/s2
Weight	Varies by model
