Omron R88D-1SN ECT Series User Manual

12 Troubleshooting
12 - 18
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
14 00 Overcurrent
Error
The current flowing to
the motor exceeded the
protection level.
There is a short circuit,
ground fault, or contact
failure on the U, V, or W
motor cable.
Correct the connection of the U, V,
or W motor cable.
There is a short circuit
on the wiring of External
Regeneration Resistor.
Correct the wiring of External
Regeneration Resistor.
The insulation resis-
tance failed between the
U, V, or W motor cable
and the motor ground
wire.
Replace the motor.
False detection due to
the noise
Take noise countermeasures.
Servo Drive failure If this event occurs again after you
performed all corrections shown
above, replace the Servo Drive.
01 Power Mod-
ule Error
An error was detected in
the power module.
There is a short circuit,
ground fault, or contact
failure on the U, V, or W
motor cable.
Correct the connection of the U, V,
or W motor cable.
There is a short circuit
on the wiring of External
Regeneration Resistor,
or the value of resis-
tance became too small.
If there is a short-circuit on the wir-
ing of External Regeneration Resis-
tor, correct the wiring.
The insulation resis-
tance failed between the
U, V, or W motor cable
and the motor ground
wire.
Replace the motor.
Servo Drive failure If this event occurs again after you
performed all corrections shown
above, replace the Servo Drive.
Error No.
Name Cause Measures
Main
(hex)
Sub
(hex)

Omron R88D-1SN ECT Series Specifications

General

Feedback	Incremental encoder, Absolute encoder
Position Control	Yes
Speed Control	Yes
Torque Control	Yes
Communication Interface	EtherCAT
Power Supply Voltage	200 to 240 VAC
Output Power	0.1 to 1.5 kW
Input Voltage Range	170 to 264 VAC
Control Method	Sine-wave PWM control
Main Circuit Power Supply	200-240 VAC
Applicable Motor Capacity	0.1 to 1.5 kW
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Encoder Error
Ambient Operating Temperature	0 to 55°C
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
Shock Resistance	98 m/s2
Weight	Varies by model
