12 Troubleshooting
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
12-5 Troubleshooting
12
12-5-1 Troubleshooting Using Error Displays
18 00 Regenera-
tion Over-
load Error
The Regeneration Load
Ratio (4310-81 hex)
exceeded the regenera-
tion overload ratio.
The regeneration pro-
cessing is set inappro-
priately.
Check the regeneration processing
setting, and set the same value as
the resistance value of the Regen-
eration Resistor in use.
The Regeneration
Resistor is selected
inappropriately.
Check the operation pattern by the
velocity monitor. Check the load
ratio of Regeneration Resistor, and
perform the following corrections
accordingly.
• Increase the deceleration time
and stopping time.
• Decrease the command velocity
to the motor.
• Use an External Regeneration
Resistor.
• Increase the capacities of the
Servo Drive and the motor.
The Regeneration
Resistor is used for con-
tinuous regenerative
braking.
The Regeneration Resistor cannot
be used for continuous regenera-
tive braking.
The applied power sup-
ply voltage is higher
than the specified value.
Apply the specified power supply
voltage.
Regeneration Resistor
failure
Check whether the Regeneration
Resistor is faulty, and use one with-
out failures.
01 Regenera-
tion Circuit
Error
*2
An regeneration circuit
error was detected.
There is a short circuit
between B2 and N2/N3.
Perform the correct wiring, referring
the cases of the connection with
peripheral devices.
Regeneration circuit fail-
ure
Replace the Servo Drive.
Noise into wiring of the
external regeneration
registor.
Take noise countermeasures by
shortening wiring or the like.
02 Regenera-
tion Process-
ing Error
The regeneration pro-
cessing was stopped to
protect the Regenera-
tion Resistor.
This error occurs when
the regeneration pro-
cessing continues for
500 ms or more.
The regeneration pro-
cessing is set inappro-
priately.
Check the regeneration processing
setting, and set the same value as
the resistance value of the Regen-
eration Resistor in use.
Error No.
Name Cause Measures
Main
(hex)
Sub
(hex)

Omron R88D-1SN ECT Series Specifications

General

Feedback	Incremental encoder, Absolute encoder
Position Control	Yes
Speed Control	Yes
Torque Control	Yes
Communication Interface	EtherCAT
Power Supply Voltage	200 to 240 VAC
Output Power	0.1 to 1.5 kW
Input Voltage Range	170 to 264 VAC
Control Method	Sine-wave PWM control
Main Circuit Power Supply	200-240 VAC
Applicable Motor Capacity	0.1 to 1.5 kW
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Encoder Error
Ambient Operating Temperature	0 to 55°C
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
Shock Resistance	98 m/s2
Weight	Varies by model
