12 Troubleshooting
12 - 48
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
Vibration is occurring
at the same fre-
quency as the power
supply.
Inductive noise is occurring. Check to see if the drive control
signal lines are too long.
Shorten the control signal lines.
Check to see if the control sig-
nal lines and power supply
lines are bound together.
• Separate control signal lines
from power supply lines.
• Use a low-impedance power
supply for control signals.
The command
velocity or torque is
not reached.
The input command value
exceeds the velocity limit value
or the torque limit value.
Check to see if the Internal limit
active bit of Statusword is
active.
Input the command value that
does not exceed the velocity
limit value or the torque limit
value from the host controller.
Symptom Probable cause Check items Measures

Omron R88D-1SN ECT Series Specifications

General

Feedback	Incremental encoder, Absolute encoder
Position Control	Yes
Speed Control	Yes
Torque Control	Yes
Communication Interface	EtherCAT
Power Supply Voltage	200 to 240 VAC
Output Power	0.1 to 1.5 kW
Input Voltage Range	170 to 264 VAC
Control Method	Sine-wave PWM control
Main Circuit Power Supply	200-240 VAC
Applicable Motor Capacity	0.1 to 1.5 kW
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Encoder Error
Ambient Operating Temperature	0 to 55°C
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
Shock Resistance	98 m/s2
Weight	Varies by model
