Appendices
A - 82
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
3321 --- 1st Notch Filter --- --- --- --- --- ---
01 Enable 0 to 1 --- 0 A 4 bytes
(INT32)
---
02 Frequency 500 to 50,000 0.1 Hz 50,000 A 4 bytes
(INT32)
---
03 Q-value 50 to 1,000 0.01 140 A 4 bytes
(INT32)
---
04 Depth 0 to 60 dB 60 A 4 bytes
(INT32)
---
81 Enable Display --- --- --- --- 4 bytes
(INT32)
---
82 Frequency Display --- 0.1 Hz --- --- 4 bytes
(INT32)
---
83 Q-value Display --- 0.01 --- --- 4 bytes
(INT32)
---
84 Depth Display --- dB --- --- 4 bytes
(INT32)
---
3322 --- 2nd Notch Filter --- --- --- --- --- ---
01 Enable 0 to 1 --- 0 A 4 bytes
(INT32)
---
02 Frequency 500 to 50,000 0.1Hz 50,000 A 4 bytes
(INT32)
---
03 Q-value 50 to 1,000 0.01 140 A 4 bytes
(INT32)
---
04 Depth 0 to 60 dB 60 A 4 bytes
(INT32)
---
81 Enable Display --- --- --- --- 4 bytes
(INT32)
---
82 Frequency Display --- 0.1 Hz --- --- 4 bytes
(INT32)
---
83 Q-value Display --- 0.01 --- --- 4 bytes
(INT32)
---
84 Depth Display --- dB --- --- 4 bytes
(INT32)
---
3323 --- 3rd Notch Filter --- --- --- --- --- ---
01 Enable 0 to 1 --- 0 A 4 bytes
(INT32)
---
02 Frequency 500 to 50,000 0.1Hz 50,000 A 4 bytes
(INT32)
---
03 Q-value 50 to 1,000 0.01 140 A 4 bytes
(INT32)
---
04 Depth 0 to 60 dB 60 A 4 bytes
(INT32)
---
81 Enable Display --- --- --- --- 4 bytes
(INT32)
---
82 Frequency Display --- 0.1 Hz --- --- 4 bytes
(INT32)
---
83 Q-value Display --- 0.01 --- --- 4 bytes
(INT32)
---
84 Depth Display --- dB --- --- 4 bytes
(INT32)
---
Index
(hex)
Sub-
index
(hex)
Object name Setting range Unit Default setting
Data
attri-
bute
Size PDO map
