1. Prepare the system as described in "Moving the System" on page 116.
2. Remove all transducers, cables, and accessories that are not attached to the
system.
3. Using a lift gate or a secured ramp, load the system into the vehicle.
4. When the system is in position, set the wheel brakes by using the appropriate
step:
• On a one-pedal system, press the foot pedal down fully.
• On a two-pedal system, press the left foot pedal down fully.
5. Place wheel chocks on the wheels to prevent the system from rolling.
6. Attach tie-down straps to the tie points on the lower rear of the system and
to the handles. Secure the straps to anchor points in the vehicle.
Tie Points on the System
123
iU22 User Manual
4535 614 45861
4
Preparing the System
