2. Click the Calcs icon , select a calc package from the menu, and click
OK.
3. Click a tab at the top of the display to select a measurement list.
4. Obtain an image and press Freeze.
5. Press Pointer, click a measurement label, and make the measurement
according to the prompts displayed at the bottom of the screen.
6. Press End Measure, if necessary, to complete the measurement. The
measurement result appears below the measurement label.
Ending an Exam
Each time you finish an exam, you must end the exam to save images, reports,
and other exam data. You can end an exam in the current exam display or with
the current exam open in the Review display. You cannot end an exam while in
the Patient Directory.
You will not be able to end the exam until the system has saved exam data for
the current exam. (The system saves exam data when you capture an image.)
Ending an exam stores all exam data, clears the Patient Data form, and prepares
for the next exam.
WARNING
Failing to end the current exam before starting a new exam can result in data
being acquired and stored under the wrong patient name.
When the exam is complete, do one of the following:
• Press End Exam.
• Click End Exam in the Patient Data display.
