Test Patterns
Two sets of test patterns are available for testing the image quality of the system,
peripheral devices, review stations, or a PACS.
• The original set of test patterns (labeled Test Patterns) includes images
intended for a variety of tests. Unlike the TG-18 test patterns, however,
these test patterns are not tied to a unified standard.
• The newest set of test patterns was created by the American Association
of Physicists in Medicine Task Group 18 (TG-18). The TG-18 test patterns
on the system were adapted for the 1024 x 768 pixel image area of the
51-cm (20-in) system monitor. For information on using these test patterns,
read IEC publication 61223-3-6 (62B/588/CD).
Transferring the Test Patterns
The test patterns are stored on a separate part of the system hard drive. You
must transfer the test patterns to a different part of the hard drive before you
can view them. The transferred test patterns remain unless you delete them.
1. Press Review.
2. Select Test Imgs from the Drive menu.
3. Select TG18 Test Patterns or Test Patterns from the exam selection
list.
4. Click Send to.
5. Select Hard Drive and click OK to transfer the images.
NOTE
To view transfer progress, click the DVD drive status icon .
Using the Test Patterns
1. Press Review.
iU22 User Manual
324
4535 614 45861
System Maintenance
14
