Philips iU22 - Preparation for Alignment Verification; Verifying the Biopsy Guide Alignment

WARNINGS
• Alignment verification is necessary before performing procedures with the
biopsy guide.
• Do not use the biopsy guide if the needle is not following the intended path.
• The needle used for this alignment verification must not be used for the
actual procedure. Always use a new, sterile needle for each biopsy
procedure.
• To assist in an accurate projection of the needle, use a straight, new needle
for each alignment procedure.
Do not use the biopsy guide if the needle is not following its indicated path.
Contact a Philips Ultrasound customer service representative.
Preparation for Alignment Verication
Assemble the following items before performing the alignment verification:
• Transducer
• Biopsy guide or bracket (The bracket is not disposable. The type of bracket
you use depends upon the transducer you are using. For the correct bracket,
contact CIVCO Medical Solutions; see "Supplies and Accessories" on page
23.)
• Needle guide (Contact CIVCO for the needle guide that fits your biopsy
guide bracket.)
• Sterile procedure kit (disposable)
• New, straight, biopsy needle
• Beaker of water (or water bath)
Verifying the Biopsy Guide Alignment
WARNING
If the needle enters from the unexpected side of the display or cannot be seen,
verify that the biopsy guide is correctly mounted on the transducer and that the
orientation of the transducer is correct. If the needle is still not following the
