Use the Freeze control to stop and start system image acquisition and update.
Pressing Freeze results in the system entering cineloop pause and assigning the
trackball to manual cineloop review (frame-by-frame).
During acquisition, a spinning hourglass icon displays at the bottom of the display.
When the capture is complete, a thumbnail of the image is displayed.
To capture a single image:
• Press Freeze and then press Print.
To capture a Cineloop sequence:
• Press Capture in live imaging or while reviewing a Cineloop sequence.
Capturing during live imaging saves prospective or retrospective frames, as
specified in Live Capture Type in the setups. A prospective capture
captures a specified acquired loop length. A retrospective capture captures
a specified loop length that was acquired previously. A retrospective capture
captures a loop that ends when Acquire is pressed. Capturing while
reviewing a Cineloop sequence saves all retrospective frames in the Cineloop
sequence.
NOTES
• When an image is captured, you will hear a beep to confirm that the loop
or image was saved in the patient's study. Do not press Review until you
hear the beep.
• If you press Capture in a non-simultaneous mode while a live M-mode or
Doppler trace is active, you capture a Cineloop sequence. If you press
Capture in a simultaneous mode, you capture a single image.
• If you attempt to capture a loop that was imported from media, only a
frame of the loop is captured and displayed in the appending exam.
Measurement and Analysis
The measurement tools appear on the Caliper touch screen. Touching an active
tool from the Caliper touch screen launches the tool. (The labels of inactive
tools are gray.)
191
iU22 User Manual
4535 614 45861
7
Performing an Exam
