Annotation
You can place text labels and arrows on an image to identify anatomical structures
and locations. You can also annotate an image with a body marker graphic that
indicates the part of the anatomy that you are scanning.
Adding Labels Using Annotate
1. Press Annotate.
2. Use the trackball to position the text cursor on the display, or touch Home
to return it to the home location.
3. Do any of the following:
• To add text, type the text that you want to appear on the display.
• To display predefined labels, touch a label control to display its text.
• To display an arrow, touch the Arrow control , position the arrow
with the trackball, and then click to fix the position.
• To erase the last word typed, touch Erase Last Word to erase words
one at a time.
• To erase all text, press the Erase Text key or touch Erase All Text.
• To erase all arrows, touch Erase Arrow.
• To move the text cursor to the home position, touch Home.
• To set a new home position, position the cursor and touch Set Home.
• To exit annotation mode, touch Close or press Annotate again.
• To use text replace, see Changing Labels Using Text Replace
Adding Labels Using the Keyboard
You can add labels using only the keyboard. You can manually format the
annotation labels you add using the keyboard. Use spaces before and after the
words you type to center the text or improve the word wrap format.
1. Press the Text Cursor key.
