L15-7io Transducer Features and Specifications
• 15 to 7 MHz extended frequency range
• Phased linear array with 128 elements
• 8 degrees of trapezoidal imaging, 23 mm (0.9 in) effective
aperture length
• Explora connector
• High-resolution intraoperative vascular applications
• Steerable PW Doppler, Color Doppler, and Color Power
Angio imaging, XRES processing, and Panoramic Imaging
Features
Lens footprint
• Elevation: 10 mm (0.4 in)
• Scan plane: 32 mm (1.25 in)
Transducer length: 89 mm (3.5 in)
Cable length: 2 m (80 in)
Specifications
Preparing Transducers for Intraoperative Use
1. Place 20 cc of sterile gel or saline into the transducer cover.
2. Carefully inspect each transducer cover before use, and discard it if you find
tears or blemishes. Also inspect each transducer cover after use. If you find
a tear, the patient or the transducer may have been contaminated.
3. Insert the transducer into the transducer cover and unfurl the transducer
cover until it covers the transducer and its cable. The cover must be unfurled
far enough to maintain the sterile field.
4. Use a sterile elastic band or clip to hold the proximal end of the transducer
cover in place.
5. Ensure that wrinkles and bubbles over the face of the transducer are
minimized. Check the transducer cover for tears or damage before proceeding.
215
iU22 User Manual
4535 614 45861
9
Intraoperative Transducers
