Foot switch
Indicates the atmospheric pressure range for
transport and storage.
SVGA connection
Two video receptacles provide DVI-D digital video
for flat-panel monitors.
S-Video connection
B/W Composite video output connection
Color composite video output connection
Video print trigger connection
Russian approval (GOST)
The following symbols may be used inside the system:
Dangerous voltages: Appears adjacent to high-voltage
terminals, indicating the presence of voltages greater
than 1,000 Vac (600 Vac in the United States).
Indicates equipotential ground.
43
iU22 User Manual
4535 614 45861
2
Safety
