Control Module Components
Control panel1
Touch screen2
Trackball3
TCG slide controls4
You can adjust the position of the control module vertically and side-to-side.
You can also swivel the control module.
Beneath the control panel is a retractable keyboard. The keyboard is used to
enter patient data, comments, and text annotation on images. A light above the
keyboard is switched on when the keyboard is pulled out.
95
iU22 User Manual
4535 614 45861
3
System Overview
