18
231
18Recording
Central
Recording
For central recording from the bedside, your monitor must be connected via a network to an
Information Center. You can use either the M1116B/C or 862120 2-Channel Recorder or the
standalone M3160A 4-Channel Recorder. Recordings made on the M3160A may look slightly different
to those described here. See the documentation supplied with the Information Center for information
on the 4-Channel Recorder.
Starting and Stopping Recordings
The recordings pop-up keys let you start and stop recordings. Select the Main Setup SmartKey then
select
Recordings to call up the line of pop-up keys. Scroll right or left to see any pop-up keys not
displayed.
Recording Without a Template
To record without a preconfigured template, selecting the waves you require,
1 Select the Main Setup SmartKey, then select Recordings.
2 Select the pop-up key Select Waves.
3 Use the pop-up keys to choose up to three measurement waves to be printed on the recording. If
you want fewer than three waves on the recording, select the waves you want then select the
Continue pop-up key.
4 Select one of the recording speed pop-up keys to set the required recording speed.
5 Select the Start pop-up key to start the recording.
Select Waves recordings use default values for any recorder settings not defined: runtime is continuous,
overlapping is set to non-overlapping.
Delayed Recordng
RT A Recordng
RT B Recordng
Select Waves
Setup Recordng
Stop All Recordng
