1 Basic Operation
27
Pop-Up Keys
Pop-up keys are task-related graphical keys that appear automatically on the monitor screen when
required. For example, the
Confirm pop-up key appears only when you need to confirm a change.
Using the On-Screen Keyboard
Use this as you would a conventional keyboard. Enter the information by selecting one character after
another. Use the
Shift and capital Lock keys to access uppercase letters. Use the Back key to delete single
characters, or use the
Clr key to delete entire entries. Select Enter to confirm what you have entered and
close the on-screen keyboard.
Operating Modes
When you switch the monitor on, it starts up in monitoring mode. To change to a different mode:
1 Select the Main Setup menu.
2 Select Operating Modes and choose the mode you require.
stop automatic or STAT NBP
measurement and measurement series
start NBP measurement and
measurement series
start veni puncture (inflate cuff to
subdiastolic pressure)
stop current NBP measurement
set the NBP repeat time access patient reports
switch CO
2
pump off zero invasive pressure transducer
new lead setup set standard or EASI lead placement
review vital signs trend review graph trend
unpair equipment and continue central
monitoring with the monitor
unpair equipment and continue central
monitoring with the telemetry device
start 12-Lead Capture (only available if
Information Center is connected)
access ST Map application
select measurement device start an SpO
2
measurement
access NBP mode selection and setup,
with direct start/stop function
open the
Equipment window
To Next Page
