Philips MP2 - Telemetry INOPs; Cableless Measurement Device INOPs

4 Patient Alarms and INOPs
81
Telemetry INOPs
Cableless Measurement Device INOPs
CCO/Tbl NoTransduc
Numeric is replaced by -?-
INOP tone
No transducer attached to the module or catheter disconnected.
Tblood Overrange
Numeric is replaced by -?-
Tblood out of range 17°C - 43°C.
TbloodNoTransducer
Numeric is replaced by -?-
INOP tone
No transducer attached to the module or catheter disconnected.
INOP Message, Indication What to do
INOP Message, Indication What to do
Check ECG Settings
INOP tone
Synchronization of ECG settings between the monitor and Information Center has failed. Check that
the ECG settings in use are appropriate.
!!Check ECG Source Both the telemetry device and the monitor have valid ECG signals
Chk SpO₂T Settings
INOP tone
Synchronization of SpO
2
T settings between the monitor and Information Center has failed. Check
that the SpO
2
T settings in use are appropriate.
Invalid Leadset The leadset plugged in cannot be used with the telemetry device.
Leadset Unplugged The leadset has been unplugged from the telemetry device.
No ECG Source A telemetry device is paired with the monitor but the Information Center is not detecting a valid ECG
signal from either of them.
!! Repl. Tele Batt
!!!Repl. Tele Batt
Severe yellow/red INOP tone
During this INOP, alarms cannot
be paused or switched off.
The battery in the telemetry device is almost empty and must be replaced.
Tele Battery Low The battery in the Telemetry device is low and must be replaced soon.
!!Tele Disconnect
!!!Tele Disconnect
Severe yellow/red INOP tone
Telemetry transceiver was disconnected or short range radio link was lost.
For cable connections; check Telemetry interface, cable connection and setup.
For short range radio connections: if the telemetry transceiver has not moved out-of-range, check for
interference sources close to the monitor (bluetooth devices, DECT phones, cellular phones,
microwaves, etc.). If this INOP persists, ask your service personnel to survey the interference sources.
!! Tele INOP
!!! Tele INOP
Severe yellow/red INOP tone
Check for further details at the Information Center or in the Telemetry Data window on the monitor.
Tele Sync Unsupp.
INOP tone
The MMS in use does not support synchronization of ECG and SpO
2
settings between the monitor
and central station after a telemetry device has been paired. Use an MMS with revision E.0 or above.
INOP Message, Indication What to do
cl NBP Batt Empty
!!cl NBP BattEmpty
!!!cl NBP BatEmpty
Corresponding INOP tone
The remaining battery time of the NBP Pod is below 30 minutes. Charge the battery.
cl NBP Batt Incomp
INOP tone
The battery in use with the NBP Pod is incompatible. Replace it with one approved for use with the
NBP Pod.
