24 Specifications
296
865297 Battery Extension Specifications
M4607A Battery Specifications
One battery is required for battery operation of the monitor.
The battery lifetime is 3 years from manufacturing date or 500 charge/discharge cycles.
M8023A External Power Supply Interface Specifications
Measurement Link
(MSL)
Connectors Male ODU (Proprietary)
Power 48 V output
Power Sync. RS-422 compliant output 78.125 kHz (typical)
LAN signals IEEE 802.3 10-Base-T compliant
Serial signals RS-422 compliant output 78.125 kHz (typical)
Local signals Not connected
865297 Battery Extension Interface Specifications
Measurement Link
(MSL)
Connectors Male ODU (Proprietary)
Power 36 -38 V output
Power Sync. RS-422 compliant output 78.125 kHz (typical)
LAN signals IEEE 802.3 10-Base-T compliant
Serial signals RS-422 compliant
Local signals Not connected
Measurement Link
(MSL)
Connectors Female ODU (Proprietary)
Power 30-60 V input
Power Sync. RS-422 compliant input 78.125 kHz (typical)
LAN signals IEEE 802.3 10-Base-T compliant
Serial signals RS-422 compliant
Local signals Not connected
865297 Battery Extension Battery Specifications
Battery Type M4605A
Indicators green power LED and green-yellow-red battery status LED
M4607A Battery Specifications
Physical Specifications
W x D x H 66 mm (2.36 in) x 80 mm (3.15 in) x 20 mm (0.79 in)
Weight 160 g ±5%
Performance Specifications
Nominal Voltage 10.8 Volt
Rated Capacity at discharge C/5 1000 mAh (typical)
Environmental Specifications
