24 Specifications
295
1
See “Connectors” on page 287 for safety-related information)
2
The short range radio interface is compatible with the IntelliVue Cableless Measurements and the following devices:
TRx4841A/TRx4851A IntelliVue Telemetry System Transceiver and MX40 Patient Wearable Monitor.
ECG Sync Pulse
Output
1
Cable detection Yes
Marker In No
Wave Output No
Connector Binder Series 709/719
Output levels Output low <0.8 V @ I = -4 mA
Output high >2.4 V @ I = 4 mA
Isolation None
Pulse Width 100 +/-10 ms (high)
Delay from R-wave peak to start
of pulse
20 ms maximum per AAMI EC13
Minimum required R-wave
amplitude
0.5 V
IntelliVue 802.11
Bedside Adapter
(Wireless Network
Adapter)
Type Internal wireless adapter
Technology IEEE 802.11a/b/g
Frequency Band USA: 2.400 - 2.483GHz, 5.15 - 5.35GHz, 5.725 - 5.825GHz
Europe: 2.400 - 2.483GHz, 5.15 - 5.35GHz, 5.47 - 5.725GHz
Japan: 2.400 - 2.483GHz, 2.471 - 2.498GHz, 4.900 - 5.091GHz, 5.150 -
5.250GHz, 5.25 - 5.35GHz, 5.470 - 5.725GHz
China: 2.400 - 2.483GHz, 5.725 -5.85GHz
Modulation Technique 802.11b/g
DSSS (DBPSK, DQPSK, CCK)
OFDM (BPSK,QPSK, 16-QAM, 64-QAM)
802.11a
OFDM (BPSK,QPSK, 16-QAM, 64-QAM)
Effective radiated power max 18 dBm
Short Range Radio
Interface
2
Type Internal SRR interface
Technology IEEE 802.15.4
Frequency Band 2.4 GHz ISM (2.400 - 2.483 GHz)
Modulation Technique DSSS (O -QPSK)
Effective radiated power max. 0 dBm (1 mW)
IntelliVue Instrument Telemetry Wireless Network (USA only)
Internal WMTS
Adapter
Technology compatible with Philips IntelliVue Telemetry System (ITS), cellular
infrastructure
Frequency Band WMTS, 1395-1400 MHz and 1427-1432 MHz
IntelliVue Instrument Telemetry Wireless Network
Internal ISM Adapter Technology compatible with Philips IntelliVue Telemetry System (ITS), cellular
infrastructure
Frequency Band 2.4 GHz ISM
Monitor Interface Specifications
