24 Specifications
301
Respiration from the CL Respiration Pod
For the general measurement specifications, refer to the IntelliVue Cableless Measurements
Instructions for Use.
The alarm specifications for alarms generated by the CL Respiration pod and indicated by the monitor
are listed in the table below.
SpO2
Complies with ISO 9919:2005 / EN ISO 9919:2009 (except alarm system; alarm system complies with
IEC 60601-2-49:2001).
Measurement Validation
The SpO
2
accuracy has been validated in human studies against arterial blood sample reference
measured with a CO-oximeter. Pulse oximeter measurements are statistically distributed, only about
two-thirds of the measurements can be expected to fall within the specified accuracy compared to CO-
oximeter measurements.
Respiration Alarm
Specifications
Range Adjustment Delay
High Adult/pedi: 10 to 100 rpm
Neo: 30 to 150 rpm
< 20 rpm: 1 rpm steps
≥ 20 rpm: 5 rpm steps
max. 14 seconds
Low Adult/pedi: 0 to 95 rpm
Neo: 0 to 145 rpm
< 20 rpm: 1 rpm steps
≥ 20 rpm: 5 rpm steps
for limits from 0 to 20 rpm:
max. 4 seconds
for limits above 20 rpm: max.
14 seconds
Apnea Alarm 10 to 40 seconds 5 second steps
cmResp Alarm Specifications Range Adjustment
Respiration Rate 5 to 60 rpm <20 rpm: 1 rpm steps
>20rpm: 5rpm steps
Bradypnea Difference to high limit 0 to 20 rpm 1 rpm steps
Clamping at 5 to 50 rpm <20 rpm: 1 rpm steps
>20rpm: 5rpm steps
Pulse 30 to 220 bpm 30 to 40 bpm: 1 bpm steps
40 to 220 bpm: 5 bpm steps
Tachycardia Difference to high limit 0 to 50 bpm 5 bpm steps
Clamping at 150 to 220 bpm 5 bpm steps
Bradycardia Difference to low limit 0 to 50 bpm 5 bpm steps
Clamping at 30 to 100 bpm 5 bpm steps
