Symbols

These symbols can appear on the monitor and its associated equipment and packaging (depending on

options).

Symbols

Caution, refer to accompanying documents On/Off/Standby

Alternating current Rechargeable battery symbol

DC power source Battery Eject

ECG Sync Pulse Output indicator Connection direction indicator

Pressure connector Temperature connector

Connection direction indicator Connector has special protection against

electric shocks and is defibrillator proof

NBP connector SpO

connector

Uses FAST SpO

algorithm LAN connection indicator for connection

to a wired network

Masimo SET technology Nellcor OxiMax compatible

Silence Alarms Alarms On/Off

Alarms Switched Off Identifies year and month of manufacture

ECG connector Error LED

IntelliVue Instrument Telemetry wireless

network

Always use separate collection for waste

electrical and electronic equipment

(WEEE)
