25 Default Settings Appendix
320
ST and QT Default Settings
Cardiotach Msg Yes Yes Yes
Some ECG Al INOP On On On
Arrhythmia Settings
Factory Defaults
Adult Pedi Neo
Lead-independent ST Settings
Factory Defaults
Adult Pedi Neo
ST Alarm Mode Single ST Single ST Single ST
Alarms On On On
ST Analysis On Off Off
ST-Index On Off Off
ISO Point
-80 ms -80 ms -80 ms
J Point 48 ms 48 ms 48 ms
ST Point J+60 J+60 J+60
Lead I, II, III, V, aVR, aVL, V1-6, MCL
Settings
Factory Defaults
Adult Pedi Neo
ST Analysis On Off Off
For Alarm Mode = Single ST
ST (Label) High +2.0 mm +2.0 mm +2.0 mm
ST (Label) Low -2.0 mm -2.0 mm -2.0 mm
For Alarm Mode =
Multi ST
ST (Label) High +1.0 mm +1.0 mm +1.0 mm
ST (Label) Low +1.0 mm +1.0 mm +1.0 mm
QT Settings
Factory Defaults
Adult Pedi Neo
QT Lead All All All
QTc High Limit
500 ms 480 ms 460 ms
ΔQTc High Limit 60 ms 60 ms 60 ms
QTc High Alarm On On On
ΔQTc High Alarm On On On
QT Analysis Off Off Off
QTc Formula Bazett Bazett Bazett
