24 Specifications
306
Measurement Validation: Clinical investigation according to ISO 81060-2:2013 with the auscultatory
reference method:
• the 5th Korotkoff sound (K5) was used in adult / adolescent subjects and the 4th Korotkoff
sound (K4) was used in pediatric subjects to determine the diastolic reference pressures.
• the approximation MAP = (2*DIA + SYS) / 3 was used to calculate reference MAP (mean arterial
pressure) values from the systolic and diastolic reference pressures.
Clinical investigation according to ISO 81060-2:2013 with the intra-arterial reference method:
• the radial artery was used for the intra-arterial reference measurement.
• the MAP values displayed by the reference invasive blood pressure monitor were used as MAP
reference values.
• blood pressure recordings with any dysrhythmias were excluded.
Measurement Time Typical at HR >60 bpm
Auto/manual/sequence:
Adult: 30 seconds
Neonatal: 25 seconds
Stat: 20 seconds
Maximum time:
Adult/pedi: 180 seconds
Neo: 90 seconds
Cuff Inflation Time Typical for normal adult cuff: Less than 10 seconds
Typical for neonatal cuff: Less than 2 seconds
Initial Cuff Inflation Pressure Adult: 165 ±15 mmHg
Pedi: 130 ±15 mmHg
Neo: 100 ±15 mmHg
Maximum Cuff Pressure Adult/Pedi: 300 mmHg
Neo: 150 mmHg
Auto Mode Repetition Times 1 min, 2 min, 2.5 min, 3 min, 10 min, 15 min, 20 min, 30 min, 45 min, 1h, 2h,
4h, 8h, 12h, 24h
STAT Mode Cycle Time 5minutes
Venipuncture Mode Inflation
Inflation Pressure Adult 20 to 120 mmHg (3 to 16 kPa)
Pediatric 20 to 80 mmHg (3 to 11 kPa)
Neonatal 20 to 50 mmHg (3 to 7 kPa)
Automatic deflation
after
Adult/pediatric 170 seconds
Neonatal 85 seconds
NBP Performance Specifications
