6 Applications, Measurement Channels
The R&S FSV/A allows you to perform all sorts of different analysis tasks on different
types of signals, e.g. W-CDMA, I/Q analysis or basic spectrum analysis. Depending on
the task or type of signal, a different set of measurement functions and parameters are
required. Therefore, the R&S FSV/A provides various applications - some of which are
included in the base unit, others are optional. The default application when you start
the R&S FSV/A is "Spectrum", for basic spectrum analysis measurements on any type
of signal.
For each application, a separate measurement channel is created, which determines
the measurement settings for that application. The same application can be activated
with different measurement settings by creating several channels for the same applica-
tion. Each channel is displayed in a separate tab on the screen.
The maximum number of measurement channels may be limited by the available
memory on the instrument.
6.1 Available Applications
Access: [MODE]
Spectrogram application
Spectrogram measurements are not a separate application, but rather a trace evalua-
tion method, thus they are available as an evaluation method for the Display Configu-
ration, not by creating a new channel. Spectrograms are configured and activated in
the "Trace" settings. See Chapter 9.5.2.1, "Working with Spectrograms", on page 498
for details.
Spectrum..................................................................................................................... 110
3G FDD BTS............................................................................................................... 110
3G FDD UE................................................................................................................. 110
5G NR..........................................................................................................................110
Amplifier.......................................................................................................................110
Analog Demodulation.................................................................................................. 111
GSM.............................................................................................................................111
I/Q Analyzer.................................................................................................................111
LTE.............................................................................................................................. 111
NB-IoT......................................................................................................................... 111
Noise Figure................................................................................................................ 111
Phase Noise................................................................................................................ 112
Pulse Measurements...................................................................................................112
Vector Signal Analysis (VSA)...................................................................................... 112
WLAN.......................................................................................................................... 112
