CALC:PSE:SUBR 10
//Sets 10 peaks per range to be stored in the list.
//--------------Performing the Measurement-----
INIT:SPUR; *WAI
//Performs a spurious emission measurement and waits until the sweep has finished.
//---------------Retrieving Results-------------
CALC:LIM1:FAIL?
//Queries the result of the check for limit line 1.
TRAC? SPUR
//Queries the peak list of the spurious emission measurement.
14.5.8 Analyzing Statistics (APD, CCDF)
All remote control commands specific to statistical measurements are described here.
● Activating Statistical Measurements..................................................................... 838
● Configuring Statistical Measurements...................................................................839
● Using Gate Ranges for Statistical Measurements................................................ 840
● Scaling the Diagram..............................................................................................842
● Performing a Statistical Measurement.................................................................. 845
● Retrieving Results.................................................................................................845
● Programming Example: Measuring Statistics....................................................... 846
14.5.8.1 Activating Statistical Measurements
The following commands activate statistical measurements.
CALCulate<n>:STATistics:APD[:STATe]............................................................................838
CALCulate<n>:STATistics:CCDF[:STATe]......................................................................... 838
CALCulate<n>:STATistics:APD[:STATe] <State>
This command turns the APD measurement on and off.
Suffix:
<n>
.
Window
Parameters:
<State> ON | OFF | 1 | 0
*RST: 0
Example:
CALC:STAT:APD ON
Switches on the APD measurement.
CALCulate<n>:STATistics:CCDF[:STATe] <State>
This command turns the CCDF on and off.
