Example:
SYST:SPE:MUTE
Manual operation: See "Audio Output Volume" on page 355
SYSTem:SPEaker:VOLume <Volume>
This command defines the volume of the built-in loudspeaker for demodulated signals.
This setting is maintained for all applications.
The command is available in the time domain in Spectrum mode and in Analog
Demodulation mode.
Parameters:
<Volume> Percentage of the maximum possible volume.
Range: 0 to 1
*RST: 0.5
Example:
SYST:SPE:VOL 0
Switches the loudspeaker to mute.
Manual operation: See "Audio Output Volume" on page 355
14.8 Analyzing Measurements (Basics)
The commands for general analysis tasks are described here.
● Zooming into the Display.......................................................................................955
● Configuring the Trace Display and Retrieving Trace Data.................................... 959
● Working with Markers............................................................................................982
● Configuring Display and Limit Lines....................................................................1040
14.8.1 Zooming into the Display
14.8.1.1 Using the Single Zoom
DISPlay[:WINDow<n>][:SUBWindow<w>]:ZOOM:AREA.................................................... 955
DISPlay[:WINDow<n>][:SUBWindow<w>]:ZOOM[:STATe]..................................................956
DISPlay[:WINDow<n>][:SUBWindow<w>]:ZOOM:AREA <x1>,<y1>,<x2>,<y2>
This command defines the zoom area.
To define a zoom area, you first have to turn the zoom on.
