R&S FSV3000 Series - Trigger and Gate Configuration

Common Measurement Settings
R&S
®
FSVA3000/ R&S
®
FSV3000
391User Manual 1178.8520.02 ─ 01
Filter Bandwidth Filter Type Application
200 kHz CFILter GSM
300 kHz CFILter
500 kHz CFILter J.83 (8-VSB DVB, USA); RF ID 14333
1 MHz CFILter CDMAone
1.228 MHz CFILter CDMAone
1.28 MHz, a=0.22 RRC TD-SCDMA
1.5 MHz CFILter DAB
2 MHz CFILter
3 MHz CFILter
3.75 MHz CFILter
3.84 MHz, a=0.22 RRC W-CDMA 3GPP
4.096 MHz, a=0.22 RRC W-CDMA NTT DOCoMo
5 MHz CFILter
10 MHz *) CFILter
20 MHz *) CFILter
28 MHz *) CFILter
40 MHz *) CFILter
80 MHz *) CFILter
*) These filters are only available with option R&S FSV3-B8 (Resolution Bandwidths > 10 MHz).
Filters larger than 10 MHz require an appropriate bandwidth extension option.
8.6 Trigger and Gate Configuration
Triggering means to capture the interesting part of the signal. Choosing the right trigger
type and configuring all trigger settings correctly allows you to detect various incidents
in your signals.
Gating allows you to restrict measurement analysis to the important part or parts of the
signal, for example bursts.
● Triggering.............................................................................................................. 392
● Gating....................................................................................................................402
