DISP:TRAC:Y:RLEV -10dBm
//Activate occupied bandwidth measurement.
CALC:MARK:FUNC:POW:SEL OBW
//Set the percentage of power to 99%.
POW:BWID 99PCT
//Set the channel bandwidth to 21 kHz.
POW:ACH:BAND 21kHz
//Optimize the instrument settings according to the channel bandwidth.
POW:ACH:PRES OBW
//Determine the ideal reference level for the measurement.
POW:ACH:PRES:RLEV
//Set the trace detector to positive peak.
DET APE
//--------------Performing the Measurement-----
//Select single sweep mode.INIT:CONT OFF
//Initiate a new measurement and waits until the sweep has finished.
INIT;*WAI
//---------------Retrieving Results-------------
//Return the occupied bandwidth.
CALC:MARK:FUNC:POW:RES? OBW
14.5.6 Measuring the Spectrum Emission Mask
All remote control commands specific to spectrum emission mask measurements are
described here.
See also Chapter 14.5.2, "Configuring Power Measurements", on page 748.
● Managing Measurement Configurations............................................................... 791
● Controlling the Measurement................................................................................793
● Configuring a Multi-SEM Measurement................................................................ 794
● Configuring a Sweep List...................................................................................... 795
● Configuring the Reference Range.........................................................................808
● Configuring the Power Classes.............................................................................810
● Configuring MSR SEM Measurements................................................................. 815
● Configuring the List Evaluation............................................................................. 821
● Performing an SEM Measurement........................................................................822
● Retrieving Results.................................................................................................822
● Example: SEM Measurement............................................................................... 823
14.5.6.1 Managing Measurement Configurations
The following commands control measurement configurations for SEM measurements.
Configuring and Performing Measurements
