14.5.6.3 Configuring a Multi-SEM Measurement
In the Spectrum application only, spectrum emissions can be measured for multiple
sub blocks of channels (see Chapter 7.6.4.5, "SEM with Multiple Sub Blocks ("Multi-
SEM")", on page 216). Up to three sub blocks (with two gaps) can be defined. For each
sub block, the familiar configuration settings concerning ranges, limit lines etc. can be
defined in individual tabs (select the sub block using the <sb> suffix in the correspond-
ing commands). In addition, settings on the sub blocks themselves must be configured.
Useful commands for multi-SEM measurements described elsewhere:
●
[SENSe:]ESPectrum<sb>:RANGe<ri>:MLCalc on page 806
Remote commands exclusive to multi-SEM measurements
[SENSe:]ESPectrum<sb>:SCENter..................................................................................794
[SENSe:]ESPectrum<sb>:SCOunt...................................................................................794
[SENSe:]ESPectrum<sb>:SCENter <Frequency>
This command defines the center frequency of the selected sub block in a Multi-SEM
measurement.
Suffix:
<sb>
.
1..n
Sub block in a Multi-SEM measurement
Parameters:
<Frequency> Frequency within the currently defined global span (see
[SENSe:]FREQuency:SPAN on page 888 and [SENSe:
]FREQuency:CENTer on page 886).
Range: 1 to 3
*RST: 1
Default unit: Hz
Example:
ESP1:SCEN 1GHZ
Manual operation: See " Sub Block / Center Freq " on page 228
[SENSe:]ESPectrum<sb>:SCOunt <Subblocks>
This command defines the number of sub blocks in the SEM measurement.
Suffix:
<sb>
.
irrelevant
Parameters:
<Subblocks> Number of sub blocks in the SEM measurement.
Range: 1 to 3
*RST: 1
Example:
ESP:SCO 2
Manual operation: See " Sub Block Count " on page 227
