Common Analysis and Display Functions
R&S
®
FSVA3000/ R&S
®
FSV3000
520User Manual 1178.8520.02 ─ 01
Example:
The import file contains trace 1, trace 2, and trace 4. The current result display has 4
active traces.
"Import to Trace" = 2: trace 2 of the import file is displayed as trace 2 in the result dis-
play.
"Import to Trace" = 3: trace 3 is not available in the import file, thus trace 1 is imported
and displayed as trace 3 in the result display
"Import to Trace" is enabled: Trace 1 is imported from the file and replaces trace 1 in
the result display.
Trace 2 is imported from the file and replaces trace 2 in the result display.
Trace 4 is imported from the file and replaces trace 4 in the result display.
Trace 3 in the result display remains unchanged.
Importing spectrogram traces
Trace data can also be imported to an active Spectrogram result display.
Note the following differences that apply in this case:
●
The measurement must be stopped before import.
●
Only trace 1 is imported to the spectrogram. Any other traces may be imported to a
Spectrum display, if available. However, they do not change the spectrogram dis-
play, which always refers to trace 1.
●
A single spectrum is inserted as a new frame number 0.
●
The trace mode is not changed to "View" as for Spectrum trace imports.
9.6.2 Trace/Data Ex/Import
Access: [TRACE] > "Trace Config" > "Trace / Data Export"
The R&S FSV/A provides various evaluation methods for the results of the performed
measurements. However, you may want to evaluate the data with other, external appli-
cations. In this case, you can export the measurement data to a standard ASCII format
file (DAT or CSV). You can also import existing trace data from a file, for example as a
reference trace (Spectrum application only).
The standard data management functions (e.g. saving or loading instrument settings)
that are available for all R&S FSV/A applications are not described here.
See Chapter 11.3, "Storing and Recalling Instrument Settings and Measurement Data",
on page 531 for a description of the standard functions.
Importing and Exporting Measurement Results for Evaluation
