7.3.9 Reference: Predefined CP/ACLR Standards
When using predefined standards for ACLR measurement, the test parameters for the
channel and adjacent-channel measurements are configured automatically.
You can select a predefined standard via the "CP / ACLR Standard" softkey in the "Ch
Power" menu or the selection list in the "General Settings" tab of the "ACLR Setup"
dialog box (see " Standard " on page 159).
Table 7-10: Predefined CP / ACLR standards with remote command parameters
Standard Remote parameter
None NONE
Multi-Standard Radio MSR
EUTRA/LTE Square EUTRa
EUTRA/LTE Square/RRC REUTra
W-CDMA 3GPP FWD FW3Gppcdma
W-CDMA 3GPP REV RW3Gppcdma
CDMA IS95A FWD F8CDma
CDMA IS95A REV R8CDma
CDMA IS95C Class 0 FWD*) FIS95c0
CDMA IS95C Class 0 REV*) RIS95c0
CDMA J-STD008 FWD F19Cdma
CDMA J-STD008 REV R19Cdma
CDMA IS95C Class 1 FWD*) FIS95c1
CDMA IS95C Class 1 REV*) RIS95c1
CDMA2000 S2CDma
TD-SCDMA FWD FTCDma
TD-SCDMA REV TRCDma
WLAN 802.11A AWLAN
WLAN 802.11B BWLAN
WIMAX WIMax
WIBRO WIBRo
GSM GSM
RFID 14443 RFID14443
TETRA TETRa
PDC PDC
PHS PHS
CDPD CDPD
Channel Power and Adjacent-Channel Power (ACLR) Measurement
