If the probe is disconnected, the offset of the probe is reset to 0.0 V.
Note: If the offset for DM-mode or CM-mode is changed, the offsets for the P-mode
and N-mode are adapted accordingly, and vice versa.
Remote command:
[SENSe:]PROBe<pb>:SETup:CMOFfset on page 926
[SENSe:]PROBe<pb>:SETup:DMOFfset on page 926
[SENSe:]PROBe<pb>:SETup:NMOFfset on page 928
[SENSe:]PROBe<pb>:SETup:PMOFfset on page 929
Attenuation
Defines the attenuation applied to the input at the probe. This setting is only available
for modular probes.
"10:1"
Attenuation by 20 dB
"2:1"
Attenuation by 6 dB
Remote command:
[SENSe:]PROBe<pb>:SETup:ATTRatio on page 926
Microbutton Action
Active Rohde & Schwarz probes (except for R&S RT-ZS10E) have a configurable
microbutton on the probe head. By pressing this button, you can perform an action on
the instrument directly from the probe.
Select the action that you want to start from the probe:
"Run Single"
Starts one data acquisition.
"No Action"
Prevents unwanted actions due to unintended usage of the microbut-
ton.
Remote command:
[SENSe:]PROBe<pb>:SETup:MODE on page 927
8.2.3 Power Sensors
The R&S FSV/A can also analyze data from a connected power sensor.
● Basics on Power Sensors..................................................................................... 316
● Power Sensor Settings..........................................................................................318
● How to Work With a Power Sensor.......................................................................322
8.2.3.1 Basics on Power Sensors
For precise power measurement, up to 4 power sensors can be connected to the
instrument via the power sensor interface (on the front panel) or the USB connectors.
Both manual operation and remote control are supported.
For a detailed list of supported sensors, see the data sheet.
Data Input and Output
