LAYout:WINDow<n>:REMove
This command removes the window specified by the suffix <n> from the display in the
active channel.
The result of this command is identical to the LAYout:REMove[:WINDow] command.
Suffix:
<n>
.
Window
Example:
LAY:WIND2:REM
Removes the result display in window 2.
Usage: Event
LAYout:WINDow<n>:REPLace <WindowType>
This command changes the window type of an existing window (specified by the suffix
<n>) in the active channel.
The effect of this command is identical to the LAYout:REPLace[:WINDow] com-
mand.
To add a new window, use the LAYout:WINDow<n>:ADD? command.
Suffix:
<n>
.
Window
Setting parameters:
<WindowType> Type of measurement window you want to replace another one
with.
See LAYout:ADD[:WINDow]? on page 876 for a list of availa-
ble window types.
Example:
LAY:WIND2:REPL MTAB
Replaces the result display in window 2 with a marker table.
Usage: Setting only
14.6.3 Examples: Configuring the Result Display
The following example demonstrates how to configure result displays in a remote envi-
ronment.
14.6.3.1 Example 1: Adding and Arranging Windows
Starting from the default initial display in the Spectrum application (Frequency Sweep),
we will configure the following result displays:
1 Frequency Sweep 3 Marker Table
2 Spectrogram 4 Marker Peak List
Configuring the Result Display
