16 Troubleshooting
If the results do not meet your expectations, the following sections may contain helpful
hints and information.
● Error Information................................................................................................. 1213
● Error Messages in Remote Control Mode...........................................................1214
● Troubleshooting Remote Operation.................................................................... 1215
● Miscellaneous Troubleshooting Hints................................................................. 1217
● Collecting Information for Support.......................................................................1218
16.1 Error Information
If errors or irregularities are detected, a keyword and an error message, if available,
are displayed in the status bar.
Depending on the type of message, the status message is indicated in varying colors.
Table 16-1: Status bar information - color coding
Color Type Description
Red Error An error occurred at the start or during a measurement, e.g. due to missing
data or wrong settings, so that the measurement cannot be started or com-
pleted correctly.
Orange Warning An irregular situation occurred during measurement, e.g. the settings no lon-
ger match the displayed results, or the connection to an external device was
interrupted temporarily.
Gray Information Information on the status of individual processing steps.
No color No errors No message displayed - normal operation.
Green Measurement
successful
Some applications visualize that the measurement was successful by show-
ing a message.
If any error information is available for a channel, an exclamation mark is displayed
next to the channel name ( ). This is particularly useful when the MultiView tab is dis-
played, as the status bar in the MultiView tab always displays the information for the
currently selected measurement only.
Furthermore, a status bit is set in the STATus:QUEStionable:EXTended:INFO reg-
ister for the application concerned (see "STATus:QUEStionable:EXTended:INFO Reg-
ister" on page 674). Messages of a specific type can be queried using the
SYST:ERR:EXT? command, see SYSTem:ERRor:EXTended? on page 1131.
