R&S FSV3000 Series User Manual

Getting Started
R&S
®
FSVA3000/ R&S
®
FSV3000
75User Manual 1178.8520.02 ─ 01
4. Tap the "Save" button.
The file MyMultiViewSetup.dfl is stored in the default directory C:/R_S/
instr/user.
To load stored instrument settings
You can restore the settings to the instrument at any time using the settings file.
1. Press the [PRESET] button to restore the default instrument settings so you can
check that the stored user settings are actually restored afterwards.
2.
Tap the "Load" icon in the toolbar.
3. In the "Load" dialog box, select the MyMultiViewSetup.dfl file in the default
directory C:/R_S/instr/user.
4. Tap the "Load" button.
All instrument settings are restored and the display should resemble Figure 5-19,
which shows the instrument display right before the settings were stored.
5.3.10 Printing and Saving Results
Finally, after a successful measurement, we will document our results. First we will
export the numeric trace data, then we will create a screenshot of the graphical display.
To export the trace data
1. Press the [TRACE] key on the front panel.
2. Tap the "Trace Config" softkey.
3. Tap the "Trace Export" tab.
4. Tap the "Export Trace to ASCII File" button.
5. Enter the file name MyMultiViewResults.
The trace data is stored to MyMultiViewResults.DAT
To create a screenshot of the display
1.
Tap the "Print immediately" icon in the toolbar.
A screenshot of the current display is created. Note that the colors on the screen
are inverted in the screenshot to improve printout results.
2. In the "Save Hardcopy as Portable Network Graphics (PNG)" dialog box, enter a
file name, e.g. MyMultiViewDisplay.
Trying Out the Instrument

R&S FSV3000 Series Specifications

General

TOI (Third-Order Intercept)	> +15 dBm
Resolution Bandwidth	1 Hz to 1 MHz
Display	12.1-inch touchscreen
Analysis Bandwidth	40 MHz
Video Bandwidth (VBW)	1 Hz to 1 MHz
Amplitude accuracy	±0.5 dB
Interface	USB
Dynamic Range	> 100 dB
