String Unit
'DBMV' dBmV
'DBUV' dBμV
'DBUA' dBμA
'DBPW' dBpW
'DBPT' dBpT
MMEMory:LOAD<n>:TFACtor <FileName>
Loads the transducer factor from the selected file in .CSV format.
Suffix:
<n>
.
irrelevant
Parameters:
<FileName> String containing the path and name of the CSV import file.
Example:
MMEM:LOAD:TFAC 'C:\TEST.CSV'
Manual operation: See " Import " on page 599
MMEMory:STORe<n>:TFACtor <FileName>, <TransdName>
This command exports transducer factor data to an ASCII (CSV) file.
For details on the file format see Chapter 12.5.3, "Reference: Transducer Factor File
Format", on page 599.
Suffix:
<n>
.
irrelevant
Parameters:
<FileName> Name of the transducer factor to be exported.
<TransdName> Name of the transducer factor to be exported.
Example:
MMEM:STOR:TFAC 'C:\TEST', 'Transducer1'
Stores the transducer factor named "Transducer1" in the file
TEST.CSV.
Manual operation: See " Export " on page 599
14.10.4 Compensating for Frequency Response Using Touchstone files
(R&S FSV/A-K544)
If the Frequency Response Correction option (R&S FSV/A-K544) is installed, the
R&S FSV/A supports the use of Touchstone (.SnP) files, as well as additional fre-
quency response correction files in .fres format.
